List of Socket E Motherboards for LGA4677 – C741 W790 Chipsets

List of Socket E Motherboards for LGA4677 - C741 W790 Chipsets

In this article, we have listed out the Socket E Motherboards for LGA4677 that comes with either the C741 or the workstation W790 chipsets.

Note: If you buy something from our links, we might earn a commission. See our disclosure statement.

Related: Best Socket P+ Motherboards

For those building powerful workstations in 2023, the choice between the C741 and W790 chipsets from Intel can be a head-scratcher. Both released last year, they offer support for the latest Intel Xeon processors, but cater to slightly different needs.

Let’s delve into the key differences to help you pick the right one for your next workstation build.

C741 vs W790 Chipset Comparison

This table compares the features of the C741 and W790 chipsets, both released in 2023 and designed for use with Intel Xeon processors.

FeatureC741W790
Release DateJanuary 2023March 2023
Price (USD)
Overclocking SupportNoYes
Bus InterfaceDMI 4.0 x8DMI 4.0 x8
CPU SupportSapphire Rapids-SP – Emerald Rapids-SP – Sapphire Rapids-WS – Sapphire Rapids-64L – Sapphire Rapids-112LSapphire Rapids-SP  – Sapphire Rapids-WS  – Sapphire Rapids-64L – Sapphire Rapids-112L
Socket Count1 or 21
Memory CapacityUp to 4 TB (1 CPU) or 8 TB (2 CPUs)Up to 2 TB (W-2400) or 4 TB (W-3400)
Maximum DIMM Slots16 (1 CPU) / 32 (2 CPUs)8 (W-2400) / 16 (W-3400)
USB 2.0 Ports1414
USB 3.2 Gen 1 Ports1010
USB 3.2 Gen 2×1 Ports10
Maximum SATA 3.0 Ports208
Processor PCI Express LanesUp to 80 lanesUp to 112 lanes
Platform PCI Express Lanes4.0 – 163.0 – 20
Independent Display SupportYesYes
Integrated WirelessNoIntel Wi-Fi 6E AX211
Discrete Wireless OptionIntel Wi-Fi 6E AX211Intel Wi-Fi 6E AX211
PCIe RAID SupportUnconfirmedUnconfirmed
SATA RAID SupportYesYes
Intel Optane Memory SupportYesYes
Intel Smart Sound TechnologyNoYes
Intel Active Management TechnologyYesYes
Trusted Execution TechnologyYesYes
vPro TechnologyYesYes
Chipset TDP11 W6 W
Chipset Package Size22 mm x 23 mm (506 mm²)28 mm x 25 mm (700 mm²)
  • This table is based on publicly available information and may not be completely accurate.
  • “Unconfirmed” features require further verification from official sources.

Core Functionality: A Solid Foundation

Both chipsets share some core functionalities. They utilize the DMI 4.0 x8 interface for communication with the CPU, and boast compatibility with a wide range of Intel Xeon processors, including the Sapphire Rapids family.

Additionally, they offer support for Intel Optane memory, maximizing storage performance, and essential security features like Trusted Execution Technology and vPro.

Scalability and Power: Cater to Your Needs

The key differentiator lies in scalability and power. The C741 shines in these aspects. It supports dual-socket configurations (1S or 2S), allowing for up to 8 TB of memory with two CPUs installed.

This caters to users who need extreme processing power and memory capacity, ideal for tasks like large-scale simulations or complex data analysis. Additionally, the C741 offers up to 80 lanes of PCI Express 5.0 for processor communication, ensuring maximum data transfer speeds between the CPU and other components.

However, with a slightly higher TDP (Thermal Design Power) of 11 W, it generates a bit more heat.

The W790, on the other hand, is designed for single-socket workstations (1S only). Its memory capacity is limited to 4 TB, catering to users who prioritize performance but don’t require the extreme scalability of the C741.

It offers a slightly lower TDP of 6 W, resulting in cooler operation. However, it compensates for the lower memory capacity with support for the faster USB 3.2 Gen 2×1 standard, offering double the bandwidth compared to the C741’s USB 3.2 Gen 1.

Additionally, the W790 boasts integrated Intel Wi-Fi 6E for convenient wireless connectivity, a feature missing in the C741.

The Overclocking Advantage: For Performance Enthusiasts

For those seeking to push their hardware to the limit, the W790 offers a significant advantage: overclocking support. This allows experienced users to manually adjust CPU clock speeds for an extra performance boost.

However, overclocking can lead to instability and increased heat generation, so it’s important to have proper cooling solutions in place.

Choosing Your Champion: Consider Your Needs

Ultimately, the best chipset for you depends on your specific needs. If you require extreme scalability, raw processing power, and a large memory footprint, the C741 is the clear winner.

However, if you prioritize features like overclocking, integrated Wi-Fi, and a slightly cooler operating temperature while still maintaining excellent performance, the W790 is a compelling choice.

List of Motherboards for LGA4677

ImageProduct NameBuy Now


ASUS Pro WS W790 SAGE SE



Check on Amazon

Check on Newegg



ASUS Pro WS W790-ACE CEB



Check on Amazon

Check on Newegg





Gigabyte MS73-HB2



Check on Gigabyte





GIGABYTE MS73-HB1



Check on Newegg





ASRock W790 WS CEB



Check on Amazon

Check on Newegg

  1. ASRock W790 WS CEB:

Check on AmazonCheck on Newegg

Specifications:

Release dateMarch 08, 2023
CPU Socket TypeLGA 4677
CPU TypeSupports 4th Gen Intel Xeon W-3400 and W-2400 Processors (LGA4677)
Supported CPU TechnologiesSupports Intel Optane Persistent Memory; Intel Boot Guard; Intel Trusted Execution Technology (Intel TXT); Intel Turbo Boost Technology; Intel Virtualization Technology (Intel VT); Intel Hyper-Threading Technology (Intel HT Technology); Intel Data Streaming Accelerator (Intel DSA); ASRock Hyper BCLK Engine
ChipsetIntel W790
Number of Memory Slots8x288pin (DDR5)
Memory StandardSupports DDR5 ECC, buffered memory (RDIMM/ RDIMM-3DS/ RDIMM-9×4) up to 6800+(OC); 1DPC Up to 6800+ MHz (OC), 4800 MHz Natively for Xeon W9, Xeon W7 and Xeon W5; 2DPC Up to 6000+ MHz (OC), 4400 MHz Natively for Xeon W9, Xeon W7 and Xeon W5; Supports 4400 MHz Natively for Xeon W3, W5-3423 and W5-3433.
Maximum Memory Supported2TB
Channel SupportedQuad Channel
PCI Express 5.0 x164 x PCIe 5.0 x16 Slots (PCIE1/PCIE3 at x16; PCIE2/PCIE5 at x8)
PCI Express 4.0 x161 x PCIe 4.0 x16 Slot (PCIE4), supports x4 mode
Other Slots1 x U.2 Connector, supports PCIe Gen4x4 (64 Gb/s) mode
SATA 6Gb/s8 x SATA3 6.0 Gb/s Connectors
M.21 x Blazing M.2 Socket (M2_1, Key M), supports type 2230/2242/2260/2280 PCIe Gen5x4 (128 Gb/s) mode; 2 x Blazing M.2 Sockets (M2_2 and M2_3, Key M), support type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode; 1 x Blazing M.2 Socket (M2_4, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
SATA RAIDSupports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices; Supports RAID 0, RAID 1, RAID 5, and RAID 10 for M.2 NVMe storage devices
Audio Chipset7.1 CH HD Audio (Realtek ALC897 Audio Codec) Nahimic Audio
Audio Channels7.1 Channels
LAN Chipset2 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s (Marvell (Aquantia) AQC113CS); 1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Intel I225LM)
Max LAN Speed2 x 10Gbps + 2.5Gbps
Wireless LAN802.11ax Wi-Fi 6E Module
BluetoothYes
Back I/O Ports2 x Antenna Ports; 1 x Optical SPDIF Out Port; 2 x USB4 Thunderbolt 4 Type-C Ports*; 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s); 4 x USB 3.2 Gen1 Ports; 3 x RJ-45 LAN Ports; 1 x BIOS Flashback Button; 1 x Line Out Jack (Gold Audio Jack); 1 x Microphone Input Jack (Gold Audio Jack)
Onboard USB2 x USB 2.0 Headers (Support 3 USB 2.0 ports); 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports); 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
Form FactorExtended ATX
Power Pin1 x 24-pin ATX Power Connector (Hi-Density Power Connector); 2 x 8-pin 12V Power Connectors (Hi-Density Power Connector) (for Motherboard); 1 x 6-pin 12V Power Connector (Hi-Density Power Connector) (for Motherboard); 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) (for PCIe card)
Windows 11Supported
  1. GIGABYTE MS73-HB1:

Check on Newegg

Specifications:

Release dateAugust 07, 2023
CPU TypeDual Intel Xeon
CPU compatible4th Gen. Intel® Xeon® Scalable Processors; Intel® Xeon® CPU Max Series
Memory support8-Channel RDIMM DDR5 per processor, 16 x DIMMs; Supports Intel® Optane Persistent Memory 300 series
ChipsetIntel® C741
Ports2 x 1Gb/s LAN ports (Intel® I210-AT); 1 x Dedicated management port; 3 x SlimSAS with 12 x SATA 6Gb/s ports; 2 x 7-pin SATA DOM 6Gb/s ports; 2 x M.2 slots with PCIe Gen4 x4 interface; 6 x PCIe Gen5 x16 expansion slots

 Gigabyte MS73-HB2:

Check on Gigabyte

Specifications:

Form FactorE-ATX 304.8W x 330.2D mm
CPU5th Generation Intel® Xeon® Scalable Processors; 4th Generation Intel® Xeon® Scalable Processors; Dual processor, CPU TDP up to 270W
Socket2 x LGA 4677 Socket E
ChipsetIntel® C741 Chipset
Memory16 x DIMM slots; DDR5 memory supported only; 8-Channel memory architecture; RDIMM modules up to 96GB supported; 3DS RDIMM modules up to 256GB supported; 5th Gen Intel® Xeon®: Up to 5600MHz; 4th Gen Intel® Xeon®: Up to 4800MHz
LAN2 x 10Gb/s BASE-T LAN ports (Broadcom® BCM57416); 2 x 1Gb/s LAN ports (Intel® I210-AT); NCSI function supported (by switch setting); 1 x 10/100/1000 management LAN
SATA3 x SlimSAS connectors for 12 x SATA 6Gb/s; 2 x SATA 6Gb/s ports
RAIDIntel® SATA RAID 0/1/10/5
Expansion SlotsSlot_6: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_0; Slot_5: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_1; Slot_4: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_1; Slot_3: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_0; Slot_2: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_0; Slot_1: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_1; 2 x M.2 slots: M-key, PCIe Gen4 x4, from CPU_0; 2280/22110 cards supported
Internal I/O1 x 24-pin ATX main power connector; 2 x 8-pin ATX 12V power connectors; 2 x 6-pin ATX 12V power connectors; 2 x M.2 slots; 2 x CPU fan headers; 4 x System fan headers; 1 x USB 3.2 Gen1 header; 1 x TPM header; 1 x VROC connector; 1 x Front panel header; 1 x Backplane board header; 1 x PMBus connector; 1 x IPMB connector; 1 x Clear CMOS jumper; 1 x BIOS recovery jumper; 1 x Buzzer
Rear I/O2 x USB 3.2 Gen1; 1 x VGA; 1 x RJ45 COM; 4 x RJ45; 1 x MLAN; 1 x ID button with LED
TPM1 x TPM header with SPI interface; Optional TPM2.0 kit: CTM010
PSU Connectors1 x 24-pin ATX main power connector; 2 x 8-pin ATX 12V power connectors; 2 x 6-pin ATX 12V power connectors
VideoIntegrated in Aspeed® AST2600; 2D Video Graphic Adapter with PCIe bus interface; 1920×1200@60Hz 32bpp, DDR4 SDRAM
Board Management featuresAspeed® AST2600 management controller; GIGABYTE Management Console (AMI MegaRAC SP-X) web interface; Dashboard; HTML5 KVM; Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.); Sensor Reading History Data; FRU Information; SEL Log in Linear Storage / Circular Storage Policy; Hardware Inventory; Fan Profile; System Firewall; Power Consumption; Power Control; Advanced power capping; LDAP / AD / RADIUS Support; Backup & Restore Configuration; Remote BIOS/BMC/CPLD Update; Event Log Filter; User Management; Media Redirection Settings; PAM Order Settings; SSL Settings; SMTP Settings
  1. ASUS Pro WS W790-ACE CEB:

Check on AmazonCheck on Newegg

Specifications:

Release dateMarch 08, 2023
CPU Socket TypeLGA 4677
CPU Type
  • Intel Socket LGA4677 for Xeon W-3400 and W-2400 Series Processors;
  • Supports Intel Turbo Boost Max Technology 3.0
ChipsetIntel W790
Number of Memory Slots8x288pin (DDR5)
Memory Standard
  • 6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/
  • 5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/
  • 4800 ECC Registered Memory
Maximum Memory Supported2TB
Channel SupportedQuad Channel
Memory FeatureSupports Intel Extreme Memory Profile (XMP)
PCI Express 5.0 x16
  • Intel Xeon W-3400 and W-2400 Series Processors;
  • 5 x PCIe 5.0 x16 slot(s)
  • (supports x16, x16, x16, x0/x8, x16/x8 modes)
SATA 6Gb/s4 x SATA 6Gb/s
M.2
  • Intel W790 Chipset; M.2_1 slot (Key M),
  • type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode);
  • M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
SATA RAID
  • Intel VROC Technology supports PCIe RAID 0/1/5/10, and
  • SATA RAID 0/1/5/10. VROC
  • HW_Key is purchased separately.
SAS
  • SlimSAS_1 slot supports PCIe 3.0 x4 mode
  • NVMe devices; SlimSAS_2 slot supports PCIe 4.0 x4 mode or
  • up to 4 SATA devices via a transfer cable.
  • The cable is purchased separately; SlimSAS_3 slot supports PCIe 4.0 x4 mode NVMe device
Audio ChipsetRealtek S1220A 7.1 Surround Sound High Definition Audio CODEC
Audio Channels7.1 Channels
LAN Chipset
  • 1 x Marvell AQtion 10Gb Ethernet;
  • 1 x Intel 2.5Gb Ethernet; ASUS LANGuard
Max LAN Speed10Gbps + 2.5Gbps
Back I/O Ports
  • 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C);
  • 4 x USB 3.2 Gen 2 port(s) (4 x Type-A);
  • 8 x USB 2.0 port(s) (8 x Type-A);
  • 1 x Marvell AQtion 10Gb Ethernet port;
  • 1 x Intel 2.5Gb Ethernet port;
  • 5 x Audio jacks; 1 x Optical S/PDIF out port;
  • 1 x BIOS FlashBack button; 1 x Clear CMOS button
Onboard USB
  • 1 x USB 3.2 Gen 2×2 connector (support(s) USB Type-C );
  • 1 x USB 3.2 Gen 1 header(s) support(s) 2 additional USB 3.2 Gen 1 ports;
  • 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports
Power Pin
  • 2 x 24-pin Main Power connector;
  • 4 x 8-pin +12V Power connector;
  • 1 x 8-pin PCIe Power connector
Windows 11Supported
Form FactorCEB
Dimensions (W x L)12.0″ x 10.5″
  1. ASUS Pro WS W790 SAGE SE:

Check on AmazonCheck on Newegg

Features:

  • Intel LGA 4677 socket in this motherboard makes it compatible with Intel Xeon W-3400 & W-2400 processors. The CPU and memory overclocking let this motherboard support up to 2TB of ECC R-DIMM DDR5 memory (1DPC).
  • You benefit from ultrafast connectivity with seven PCIe 5.0 x16 slots, three M.2, dual Intel X710-AT2 10G LAN, USB 3.2 Gen 2×2 Type-C®, and two SlimSAS.
  • Server-grade IPMI remote management is implemented at the hardware and software level. This along with a dedicated LAN port can connect to the AST2600 BMC controller.
  • ASUS Control Center Express (a real-time monitoring and management software) is included.
  • It boasts robust power and thermal design that includes 14+1+1 power stages, 8-pin & 6-pin PCIe power connectors, chipset, Massive VRM, M.2 backplates, and M.2 heatsinks.
  • To ensure stability, the motherboard is compatible with the latest technologies with a solid QVL list. It has been tested for 24/7 operation.

Specifications:

Release dateMarch 08, 2023
CPU Socket TypeLGA 4677
CPU TypeIntel Socket LGA4677 for Xeon W-3400 and

W-2400 Series Processors

ChipsetIntel W790
Onboard Video Chipset1 x VGA port from AST2600
Number of Memory Slots8x288pin (DDR5)
Memory StandardDDR5;6800(OC)/6600(OC)/

6400(OC)/6200(OC)/

6000(OC)/5800(OC)/

5600(OC)/5400(OC)/

5200(OC)/5000(OC)/4800 ECC Registered Memory

Maximum Memory Supported2TB
Channel SupportedEight Channel
Memory FeatureSupports Intel Extreme Memory Profile (XMP)
PCI Express 5.0 x16Intel Xeon W-3400 Series Processors:

7 x PCIe 5.0 slot(s) (Seven at x16/x16/x16/x16/x16/x8/x16);

Intel Xeon W-2400 Series Processors:

4 x PCIe 5.0 slot(s) (Four at x16/x16/x16/x16)

SATA 6Gb/s8 x SATA 6Gb/s
M.2Intel Xeon W-3400 Series Processors: M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode); M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode); Intel W790 Chipet: M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
SATA RAIDIntel VROC Technology supports PCIe RAID 0/1/5/10, and SATA RAID 0/1/5/10. VROC_HW_Key is purchased separately.
Audio ChipsetRealtek S1220A 7.1 Surround Sound High Definition Audio CODEC
Audio Channels7.1 Channels
LAN Chipset
  • 1 x Intel dual 10Gb Ethernet;
  • 1 x Realtek 1Gb Ethernet;
  • ASUS LANGuard
Max LAN Speed2 x 10Gbps + 1Gbps
Back I/O Ports
  • 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C);
  • 5 x USB 3.2 Gen 2 port(s) (4 x Type-A + 1 x USB Type-C);
  • 2 x USB 2.0 port(s) (2 x Type-A);
  • 1 x VGA port; 2 x Intel dual 10Gb Ethernet ports;
  • 1 x Realtek 1Gb Ethernet port;
  • 5 x Audio jacks; 1 x Optical S/PDIF out port;
  • 1 x BIOS FlashBack button; 1 x Clear CMOS button
Onboard USB
  • 1 x USB 3.2 Gen 2 connector (support(s) USB Type-C );
  • 1 x USB 3.2 Gen 1 header(s) support(s)
  • 2 additional USB 3.2 Gen 1 ports; 2 x USB 2.0 header(s) support(s)
  • 4 additional USB 2.0 ports
Form FactorEEB
Power Pin
  • 2 x 24-pin Main Power connector;
  • 4 x 8-pin +12V Power connector;
  • 1 x 8-pin PCIe Power connector;
  • 1 x 6-pin PCIe Power connector
Windows 11Supported
Dimensions and weight‎14.96 x 14.17 x 3.07 inches; 8.82 pounds

Conclusion

The C741 and W790 chipsets are both strong contenders in the world of high-performance workstations.

By understanding their strengths and weaknesses, you can make an informed decision based on your specific needs.

Whether you require the raw power and scalability of the C741 or prioritize features like overclocking and integrated Wi-Fi offered by the W790, there’s a perfect chipset waiting to unleash the potential of your next workstation build.

So, research thoroughly, consider your workflow demands, and get ready to experience the power of these cutting-edge chipsets!
