Storage Systems

Compare BX500 vs MX500 vs WD Green Specifications

BX500 vs MX500 vs WD Green

This article compares the BX500 vs MX500 vs WD Green, which are entry-level SSDs that offer excellent performance and value.

Note: If you buy something from our links, we might earn a commission. See our affiliate disclosure statement.

Related: Wd Black SN750 vs Sabrent Rocket 3 vs Samsung 970 Evo Plus

When SSDs were introduced, they were pretty expensive. They drastically reduced seek times, in addition, to read & write performance. In fact, what makes SSDs one of the best options in comparison to HDDs is the lack of moving parts and thus overcomes the physical limitations. The SSD, being a NAND instead of spindles, removes one of the enormous IOPS bottlenecks in the computing world.

Also Read: Crucial BX500 vs MX500 vs Kingston A400 Specifications Comparison

Crucial BX500 vs MX500 vs Kingston A400

Features / ParticularsCrucial MX500

Check on Amazon

Crucial BX500

Check on Amazon

Kingston A400

Check on Amazon

Form Factor2.5 inch SATA SSD

M.2 2280 SSD

2.5 inch SATA SSD



2.5 inch SATA SSD



InterfaceSATA 6 GB per secSATA 6 GB per secSATA 6 GB per sec
Capacities available250 GB (SATA, M.2)

500 GB (SATA, M.2)

1 TB (SATA, M.2)

2 TB (SATA)

120 GB

240 GB

480 GB

120 GB

240 GB

480 GB

960 GB

Sequential read speed560 MB per sec540 MB per sec500 MB per sec
Sequential Write speed510 MB per sec500 MB per sec320 MB / s (120 GB)

350 MB / s (240 GB)

450 MB / s (480 GB, 960 GB)

Lifetime1.8 Million hours1.5 million hours1.0 million hours
Load capacity in TBW100 TB (250 GB)

180 TB (500 GB)

360 TB (1 TB)

700 TB (2 TB)

40TB (120GB)

80TB (240GB)

120TB (480GB)

40 TB (120 GB)

80 TB (240 GB)

160 TB (480 GB)

300 TB (960 GB)

Warranty5 years3 years3 years

Crucial BX500

Check on Amazon

Crucial has been one of the best options when you look ahead to faster performance. Of course, it is the more expensive option for most of your entry-level requirements. However, the SSD is a little behind in terms of performance compared to the competition.

The SSD comes with a sequential read speed of 540 MB per sec and a sequential write speed of 500 MB per sec. However, this should be compensated with the fact that the Crucial BX500 is cheaper than the MX300. The drive is available in SATA SSD format and comes in varied capacity options like 120GB, 240GB, and 480GB alternatives. The SSD is quite comparable to the WD’s Green range of DDS options.

The drive comes with secure installation options along with the Acronis’ True Image software that can help clone your existing hard drive. The endurance limit for the drive would read between 40 TBW and 120 TBW.

A few salient features offered by the product would include:

  • A faster boot-up performance. You will find your files loading real faster.
  • You will find the overall system responsiveness improvement
  • The drive is faster by around 300 percent when compared to an average Hard drive performance
  • The SSD comes equipped with tools specifically designed for easy installation.
  • You have access to a three-year warranty

The Pros

  • One of the best performance to price ratio
  • An excellent three-year warranty.
  • An extremely affordable option.
  • A high-end support mechanism.

The Cons

  • The maximum capacity available is just 450 GB.
  • The plastic build might not last long.
  • It is not available in the M.2 form factor

The WD Green: Specs

Check on Amazon

Specifications2TB1TB
Model Number
WD Green SSD 2.5”/7mmcasedWDS200T2G0AWDS100T2G0A
WD Green SSD M.2 2280
Interface
WD Green SSD 2.5”/7mmcasedSATA III 6 Gb/sSATA III 6 Gb/s
WD Green SSD M.2 2280SATA III 6 Gb/sSATA III 6 Gb/s
Performance 4 [4KB QD32]
Sequential Read up to (MB/s)545545
Power5
Avg. Active Power (mW)8080
Max Read Operating (mW)2,3002,800
Max Write Operating (mW)3,1002,800
Slumber (mW)3030
DEVSLP (mW)1010
Reliability
MTTF6Up to 1.0M hoursUp to 1.0M hours
Environmental
Operating Temperatures0°C to 70°C0°C to 70°C
Non-operating Temperatures-55°C to 85°C-55°C to 85°C
Operating Vibration5.0 gRMS, 10-2000 Hz5.0 gRMS, 10-2000 Hz
Non-operating Vibration4.9 gRMS, 7-800 Hz4.9 gRMS, 7-800 Hz
Shock1,500 G @ 0.5 msec halfsine1,500 G @ 0.5 msec halfsine
CertificationsFCC, UL, TUV, KC, BSMI, VCCI, CE, Morocco, RCM, CAN ICES-3(B)/NMB-3(B)FCC, UL, TUV, KC, BSMI, VCCI, CE, Morocco, RCM, CAN ICES-3(B)/NMB-3(B)
Limited Warranty3 years3 years
Physical Dimensions100.50mm x 69.85mm x100.50mm x 69.85mm x
Size: 2.5”/7mm cased7.00mm7.00mm
Size: M.2 228080mm x 22.0mm x 1.5mm80mm x 22.0mm x 1.5mm
Weight: 2.5”/7mm cased32.7g, ± 0.5g32.7g, ± 0.5g
Weight: M.2 22806.52g, ± 0.5g6.52g, ± 0.5g

* Product Specs are subject to change; please visit vendor website for up to date information

Specifications480GB240GB120GB
Model Number1
WD Green SSD 2.5”/7mmcasedWDS480G2G0AWDS240G2G0AWDS120G2G0A
WD Green SSD M.2 2280WDS480G2G0BWDS240G2G0BWDS120G2G0B
Interface2,3
WD Green SSD 2.5”/7mmcasedSATA III 6 Gb/sSATA III 6 Gb/sSATA III 6 Gb/s
WD Green SSD M.2 2280SATA III 6 Gb/sSATA III 6 Gb/sSATA III 6 Gb/s
Performance 4 [4KB QD32]
Sequential Read up to (MB/s)545545545
Power5
Avg. Active Power (mW)808080
Max Read Operating (mW)2,8002,8002,200
Max Write Operating (mW)2,8002,8002,200
Slumber (mW)303030
DEVSLP (mW)101010
Reliability
MTTF6Up to 1.0M hoursUp to 1.0M hoursUp to 1.0M hours
Environmental
Operating Temperatures0°C to 70°C0°C to 70°C0°C to 70°C
Non-operating Temperatures-55°C to 85°C-55°C to 85°C-55°C to 85°C
Operating Vibration5.0 gRMS, 10-2000 Hz5.0 gRMS, 10-2000 Hz5.0 gRMS, 10-2000 Hz
Non-operating Vibration4.9 gRMS, 7-800 Hz4.9 gRMS, 7-800 Hz4.9 gRMS, 7-800 Hz
Shock1,500 G @ 0.5 msec halfsine1,500 G @ 0.5 msec halfsine1,500 G @ 0.5 msec halfsine
CertificationsFCC, UL, TUV, KC, BSMI, VCCI, CE, Morocco, RCM, CAN ICES-3(B)/NMB-3(B)FCC, UL, TUV, KC, BSMI, VCCI, CE, Morocco, RCM, CAN ICES-3(B)/NMB-3(B)FCC, UL, TUV, KC, BSMI, VCCI, CE, Morocco, RCM, CAN ICES-3(B)/NMB-3(B)
Limited Warranty73 years3 years3 years
Physical Dimensions
100.50mm x 69.85mm x100.50mm x 69.85mm x100.50mm x 69.85mm x
Size: 2.5”/7mm cased7.00mm7.00mm7.00mm
Size: M.2 228080mm x 22.0mm x 1.5mm80mm x 22.0mm x 1.5mm80mm x 22.0mm x 1.5mm
Weight: 2.5”/7mm cased32.7g, ± 0.5g32.2g, ± 0.5g32.1g, ± 0.5g
Weight: M.2 22806.52g, ± 0.5g6.51g, ± 0.5g6.46g, ± 0.5g

WD green is one of the affordable SSD options made available by Western Digital and provides you access to one of the best features in terms of functionality. You will find the drive coming in multiple options that offer you right from 120 GB to 450 GB capacities.

The drive should be one of the best choices to go with laptops and desktop computers. This should be the perfect option for high performance and a great deal of reliability. It is even more interesting than the drive is available in both 2.5”/ 7 mm and M.2  2280 form factors. They are quite compatible with almost all your PCs and laptops.

The drive is specially designed for use with the budget segment. The SSD comes with Silicon Motion SM2258XT as a controller.

The controller comes with a RAM-less design. This would be one of the best cost-saving options; you would love to go with the affordable alternatives.

You have access to 540 MB per sec sequential read speeds and sequential write speeds of 458 MB per sec. That would make the Crucial BX500 a clear winner in comparison.

Some of the best features offered by WD Green include:

  • Enhanced performance for your day-to-day computing requirements.
  • Get the best solid-state reliability. The lightweight and shock-resistant performance should make it one of the best options to go with.
  • You will have access to higher performance with lower power requirements.
  • The three-year limited warranty should make it one of the prominent choices.
  • The free and downloadable Western Digital SSD software should ideally make it an excellent choice for enhanced performance.

The Pros

  • The SSD drive comes with an economical design.
  • You will find it offers the best possible transfer speed options.

The Cons

  • The IO latency timings appear to be slightly higher
  • The build quality is one of the issues

The Comparison chart for the WD Green and Crucial BX500

Having checked out the best features and functions offered by the two competing players like Crucial BX500 and WD Green, here is a complete side-by-side comparison between the two SSD drives. This will help you understand the features offered by the products more effectively and help you pick the best options based on the qualities you are looking ahead to.

Features  / ParticularsCrucial BX500

Check on Amazon

Western Digital WD Green

Check on Amazon

Capacities available120GB, 240 GB and 480 GB120 GB, 240 GB, 480 GB and 1 TB
Form Factor2.5” 7 mm2.5” 7 mm and M.2 2280
Interface SATA III 6GB per secSATA 6 GB per sec
Sequential read speed540 MB per sec545 MB per sec
Sequential write speed500 MB per sec458 MB per sec
Memory type Micron® 3D NANDNA
MTTF1.5 M hoursUp to 1.0 M hours
Endurance120GB: 40TB total bytes written (TBW)

240GB: 80TB total bytes written (TBW)

480GB: 120TB total bytes written (TBW)

NA
Physical dimensions3.75 x 5.0 x 0.5 inches100.5 x 69.85 x 7 mm
Weight55 grams32.7 grams

Those were just a few features that would differentiate the two competing solid-state drives. The functionality should provide you with good input into what these drives would offer you.

The Concluding Thoughts

The WD Green is perhaps something that you would not find anything near enough to the performance shown by the Crucial BX500. However, if you are looking for excellent endurance levels from your SSD drives, we recommend opting for the Crucial BX500 over the WD Green SSD. The read speed performance of the WD Green is quite limited and lower when compared to the Crucial BX500.

Check out the features as outlined in this comparison and share your experiences with us.
