By IG Share Share NAS Drive Comparison: WD Red vs Seagate IronWolf (4TB) F faceofit.com NAS Drive Comparison Guide WD Red vs Seagate IronWolf - 4TB Models Deep Dive Note: If you buy something from our links, we might earn a commission. See our disclosure statement. 📊 All Drives View 🔄 Side-by-Side Mode 🔍 Detailed Comparison ✓ WD Red WD40EFAX Recording SMR Speed 5400 RPM Transfer Rate 180 MB/s Cache 256 MB Workload 180 TB/year MTBF 1M hours Warranty 3 years + Rescue Power (Active) 4.8W Best For 1-8 bay SOHO Balanced 🛒 Check on Amazon 🛒 Check on Newegg ✓ IronWolf Pro ST4000NE00253 Recording CMR Speed 7200 RPM Transfer Rate 214 MB/s Cache 256 MB Workload 300 TB/year MTBF 1.2M hours Warranty 5 years + Rescue Power (Active) 9.0W Best For Up to 16 bay SMB Pro Features 🛒 Check on Amazon 🛒 Check on Newegg × Detailed Drive Comparison Compare any two drives side-by-side with detailed analysis Drive 1: WD Red (WD40EFAX) WD Red Pro (WD4005FFBX) Seagate IronWolf (ST4000VN006) Seagate IronWolf Pro (ST4000NE00253) Drive 2: WD Red (WD40EFAX) WD Red Pro (WD4005FFBX) Seagate IronWolf (ST4000VN006) Seagate IronWolf Pro (ST4000NE00253) Specification WD Red Seagate IronWolf Analysis Use Case Recommendations 🏠 Home & SOHO NAS (1-8 bay) For personal backups, media streaming, and light RAID arrays. Focus on value and reliability for home users. WD Red Seagate IronWolf 💼 SMB & Creative Pros (up to 16 bay) For intensive multi-user environments, video editing, and business-critical data. Performance and endurance are key. WD Red Pro Seagate IronWolf Pro Key Differentiators 💿 Recording Technology WD Red uses SMR for higher capacity efficiency, while all others use CMR for consistent performance in RAID. ⚡ Performance Leaders WD Red Pro leads with 217 MB/s transfers and 550 TB/year workload rating - best for heavy usage. 🛡️ Data Protection Seagate offers unique Rescue Data Recovery plans - IronWolf gets 4 years, Pro includes 2 years. 🔧 NAS Technologies WD uses NASware 3.0, Seagate employs AgileArray with dual-plane balancing and RV sensors. 💰 Value Proposition Standard models offer 3-year warranties for budget builds; Pro versions extend to 5 years for business use. 🔊 Noise & Power WD Red and IronWolf standard models are most power-efficient at 4.8W. Pro models consume more power (6-9W) but deliver superior performance. BF 1M hours Warranty 3 years Power (Active) 4.8W Best For 2-6 bay home NAS Budget Option 🛒 Check on Amazon 🛒 Check on Newegg ✓ WD Red Pro WD4005FFBX Recording CMR Speed 7200 RPM Transfer Rate 217 MB/s Cache 256 MB Workload 550 TB/year MTBF 2.5M hours Warranty 5 years Power (Active) ~6-7W est. Best For Multi-bay RAID Performance 🛒 Check on Amazon 🛒 Check on Newegg ✓ IronWolf ST4000VN006 Recording CMR Speed 5400 RPM Transfer Rate 202 MB/s Cache 256 MB Workload 180 TB/year MT Affiliate Disclosure: Faceofit.com is a participant in the Amazon Services LLC Associates Program. As an Amazon Associate we earn from qualifying purchases. Share What's your reaction? Excited 0 Happy 0 In Love 0 Not Sure 0 Silly 0
