Biostar TB250 BTC PRO Review

In this post, we are going to do a quick Biostar TB250 BTC PRO Review of its specifications. The Crypto-currency mining market has been revitalized, thanks to the sky-high cryptocurrency prices with double-digit growth. GPU assisted mining has been the common cost-effective way of entering the Crypto-currency market. BIOSTAR has been delivering innovative products in this field that encouraged many practitioners as well as investors in formulating platforms for this business. BIOSTAR after the H81A & TB85 series has been favorited by the mining community for its balance of price and scalability extending support of up to six graphics cards for highest motherboard utilization.

After an initial demo at Computex 2017 with 6 GPUs, Biostar released the TB250-BTC PRO which happens to be the world’s first motherboard that can hold up to 12 graphics cards concurrently. It helps in allowing 200% increase in motherboard utilization and more ROI.

Biostar TB250 BTC PRO Review

Buy From Amazon Buy From Newegg

At the moment, TB250-BTC Pro one of the top mining motherboard that goes beyond traditional offerings. It is said to be twice as powerful compared to the former model. It is equipped with 12 native PCIe slots which can support up to 12 graphics card. This motherboard is already launched globally and for the mining market, there is very little competition.

Check out its high-level specifications below:

Chipset Intel B250 Chipset
CPU Support Supports all 7th generation Core processors from Intel

Intel Core i7, Core i5, Intel Core i3,
Intel Pentium & Intel Celeron LGA-1151 Processor
Form Factor /Socket Type ATX Form-factor

Intel Socket LGA 1151
Power Connections 24 pin EATX main power connector

8 pin ATX12V power connector
RAM slots Supports Dual-Channel DDR4 2400/ 2133 & 1866 MHz

2 x DDR4 DIMM Memory-Slot

Supports up to 32 GB of DDR4 main memory
Storage interface 6 * SATA 3.0 Connector
Expansion slots 1x CPU

2x DIMM 288 pin

1x PCIe 3.0 x16

11 x PCI-E x1 (3.0 Slot)
Networking Realtek RTL8111H – 10/100/1000 GBe Ethernet Controller

Supports Super LAN Surge-Protection
Audio  Realtek ALC887 8-Channel HD Audio
USB Ports 4x USB 3.0 (5 Gbps)

2 x USB 2.0

2x USB 2.0 ports

1 x USB 3.0 Header

2 x USB 2.0 Header
Dimension  29.5cm x 21cm
Features  100% Solid capacitor

Double mining power:

As mentioned before, TB250-BTC Pro is twice powerful compared to the TB250-BTC version. For the same performance, it can save you a lot of bucks by having one system instead of two. For example for using 12 graphics cards, you need to build two builds with TB250-BTC and require two CPUs, two SSDs, two memory sets and two power supplies. However, a single TB250-BTC Pro build will allow you to use 12 graphics card with single CPU, SSD, etc. So ultimately:

“TB250-BTC PRO = TB250-BTC + TB250-BTC”

It will maximize the mining performance by 200%. It will increase the profitability with less time to spend and increases return level. It makes the mining efficient with its impressive hash rate and mining performance. Biostar guarantees that you would get the best output in 79 days. Compared to two sets of TB250-BTC, it is 18 days less! This mobo would help you bring out the best of your time and money. After all, the less you spend, the more you earn. Consider the following table:

Motherboard/s Graphics Cards Hash Rate ROI
1x TB250-BTC Pro 6x AMD RX 470

6x Nvidia GTX 1060

 246.6 MH/s 79 Days
2x TB250-BTC 6x AMD RX 470 134.4 MH/s 97 Days
6x Nvidia GTX 1060 112.2 MH/s

Neat Slot Layout:

Since there are so many PCIe slots, it is required that the manufacturer places the slots in a neat layout and Biostar doesn’t disappoint here. They are evenly equipped on the motherboard so that there is zero risk of the short circuit while mining. It is perfect since professional miners want their mining process to go on stable and without obstacles.

Native PCIe for Enhanced Compatibility:

All 12 PCIe slots on this mobo are native PCIe used in Intel B250 chipset. Many mining motherboards offer PCIe bridge solution that allows expanding more PCIe slots. However, there is a possibility of compatibility and stability issues in such motherboards. TB250-BTC Pro is completely superior to them as all PCIe slots are native ones. They come from top-notch Intel B250 chipset, unlike some other low-quality motherboards that offer Intel H110 chipset.

For mining enthusiast, it is a perfect mining environment setup. Native slots are considered highly vital for GPU mining since they help GPUs operate with improved stability, compatibility and speed. Altogether, these features make it an ultimate mining motherboard as it provides very robust base and environment for every mining enthusiast.

Hybrid Graphics Card Support:

Professional miners always face a stock problem as they are always looking for hot selling high-performance crypto mining graphics card such as AMD RX 470. However, this motherboard supports hybrid graphics cards. Means, you can use six pieces of AMD RX 470 and six pieces of Nvidia GTX 1060. However, due to drive limitations, you can use maximum eight graphics cards of each type. This makes following combinations possible:

Conclusion

We hope you like our Biostar TB250 BTC PRO Review. For feedbacks and questions, feel free to drop us a comment below in the comments section.
